Description
The 160A NH00 1P Fuse is a specific type of fuse link designed for electrical protection in industrial applications. Here’s a comprehensive overview based on the information available:
Product Specifications:
-
Poles: 1 Pole (1P)
-
Type: NH00 (also known as NH Size 00)
-
Voltage Rating:
-
AC: Typically up to 500V AC or 660V AC depending on the manufacturer.
-
DC: Can vary; common ratings include 250V DC or 440V DC for some models.
-
Design and Features:
-
Construction:
-
The fuse link has a ceramic body for insulation and heat resistance, with copper or silver-plated contacts for conductivity.
-
It features blade contacts (knife edge) for easy insertion into NH fuse holders or bases.
-
-
Indicators: Often includes dual indicators for blown fuse detection.
-
Protection:
-
gG (general purpose) or gL (full range breaking capacity) characteristics, providing protection against overloads and short circuits.
-
High breaking capacity, often up to 120kA for AC, ensuring it can interrupt very high short-circuit currents.
-
