Description
- Max. current rating 250 A
- Max. Voltage rating 70 VDC
- Terminal diameter 5/16 inch / 8 mm
- Terminal height 0.67 inch / 17 mm
- Terminal material Stainless steel
- Hex nut material Tin-plated copper
- Recommended torque 110 lbf·inch / 13 N·m
- Busbar strip material Tin-plated copper (5 x 24 mm)
- Base material ABS, black, UL 94 V-0
- Cover material ABS, black, UL 94 V-2
- Weight, 4 terminals 0,24 kg
- Dimensions (hxwxd) (with cover) 48 x 237 x 70 mm
- Weight, 6 terminals 0,43 kg
- Dimensions (hxwxd) (with cover) 48 x 237 x 70 mm
